We supply large series of Carbon Fiber Rods/Tubes ( outer dia. from 0.5mm to 51mm), square tubes, rectangular tubes, profiles ,etc. Our Carbon Fiber Reinforced Plastic (CFRP) products are strong, light,rigid etc,unit length is also on your request
Our pultruded carbon sections offer the ultimate cost-effective carbon solution. Manufactured to high tolerances using either vinlyester or epoxy resins combined with carbon fiber in a continuous process our pultruded profiles offer extremely high strength and stiffness.
Our products are suitable for Tent , kites, toys, model, planes, tool handle, golfbags, golftraining nets,other sports apparatuses play a supporting role.
Product Feature:
Light Weight ,high Strength
High Corrosion Resistance
Wide Temperature Range Use
Consistent Cross Section
Environmentally Safe
| Carbon Fiber Round Solid Rod |
| ITEM |
OD
/mm |
OD
/Inch |
Length
m/m |
Weight
gram/Meter |
| SC-CR-01 |
0.5 |
0.020 |
1000 |
0.3 |
| SC-CR-02 |
0.6 |
0.024 |
1000 |
0.4 |
| SC-CR-03 |
0.7 |
0.028 |
1000 |
0.6 |
| SC-CR-04 |
0.8 |
0.031 |
1000 |
0.8 |
| SC-CR-05 |
1.0 |
0.039 |
1000 |
1.2 |
| SC-CR-06 |
1.2 |
0.047 |
1000 |
1.7 |
| SC-CR-07 |
1.3 |
0.051 |
1000 |
2.0 |
| SC-CR-08 |
1.5 |
0.059 |
1000 |
2.7 |
| SC-CR-09 |
1.8 |
0.071 |
1000 |
3.9 |
| SC-CR-10 |
2.0 |
0.079 |
1000 |
4.8 |
| SC-CR-11 |
2.5 |
0.098 |
1000 |
7.5 |
| SC-CR-12 |
3.0 |
0.118 |
1000 |
10.8 |
| SC-CR-13 |
3.2 |
0.126 |
1000 |
12.3 |
| SC-CR-14 |
3.5 |
0.138 |
1000 |
14.7 |
| SC-CR-15 |
4.0 |
0.157 |
1000 |
19.2 |
| SC-CR-16 |
4.5 |
0.177 |
1000 |
24.3 |
| SC-CR-17 |
5.0 |
0.197 |
1000 |
30.0 |
| SC-CR-18 |
5.5 |
0.217 |
1000 |
36.3 |
| SC-CR-19 |
6.0 |
0.236 |
1000 |
43.2 |
| SC-CR-20 |
6.1 |
0.240 |
1000 |
44.7 |
| SC-CR-21 |
6.3 |
0.248 |
1000 |
47.6 |
| SC-CR-22 |
6.5 |
0.256 |
1000 |
50.7 |
| SC-CR-23 |
7.0 |
0.276 |
1000 |
58.8 |
| SC-CR-24 |
7.5 |
0.295 |
1000 |
67.5 |
| SC-CR-25 |
7.9 |
0.311 |
1000 |
74.9 |
| SC-CR-26 |
8.0 |
0.315 |
1000 |
76.8 |
| SC-CR-27 |
8.5 |
0.335 |
1000 |
86.7 |
| SC-CR-28 |
9.0 |
0.354 |
1000 |
97.2 |
| SC-CR-29 |
9.5 |
0.374 |
1000 |
108.3 |
| SC-CR-30 |
10.0 |
0.394 |
1000 |
120.0 |
| SC-CR-31 |
10.5 |
0.413 |
1000 |
132.3 |
| SC-CR-32 |
11.0 |
0.433 |
1000 |
145.2 |
| SC-CR-33 |
12.0 |
0.472 |
1000 |
172.8 |
| SC-CR-34 |
12.5 |
0.492 |
1000 |
187.5 |
| SC-CR-35 |
12.7 |
0.500 |
1000 |
193.5 |
| SC-CR-36 |
14.0 |
0.551 |
1000 |
235.2 |
| SC-CR-37 |
15.0 |
0.591 |
1000 |
270.0 |
| SC-CR-38 |
16.0 |
0.630 |
1000 |
307.2 |
| SC-CR-39 |
18.0 |
0.709 |
1000 |
388.8 |
| SC-CR-40 |
19.0 |
0.748 |
1000 |
433.2 |
| SC-CR-41 |
20.0 |
0.787 |
1000 |
480.0 |
| SC-CR-42 |
22.0 |
0.866 |
1000 |
580.8 |
| SC-CR-43 |
25.0 |
0.984 |
1000 |
750.0 |
| SC-CR-44 |
27.0 |
1.063 |
1000 |
874.8 |
| SC-CR-45 |
30.0 |
1.181 |
1000 |
1080.0 |
